SPECIFICATION
RECORRIDO HORQUILLA
Carbon
CUADRO
Carbon technology frame, 150mm F.O.L.D. GEN3 kinematics, 148×12 thru axle, internal cable routing, Post Mount 180 mm
HORQUILLA
FOX 36 Float Rhythm 29 E-Bike, Grip, 110 x 15 mm, 44 mm rake
RECORRIDO DE LA HORQUILLA DE SUSPENSIÓN
160 mm
AMORTIGUADOR
OX Float DPS, 3-position lever, 210/55 mm, hardware: 25.0 x 8.0 mm, no Bushing
MOTOR
Fazua Ride 60, 60 Nm, 450 W max.
WH BATERÍA
430 Wh
BATERÍA AMPERIOS HORAS
10 Ah
MOSTRAR
Fazua LED Hub + Ring Control
PULSADORES
Shimano Deore XT M8100, 12-speed
CAMBIO
Shimano Deore XT M8100, 12-speed
CASSETTE
Shimano Deore CS-M6100, 12-speed
CADENA
Shimano Deore CN-M6100, 12-speed
BIELAS
Rotor eKAPIC RF Link 29
DESARROLLOS
front: 32, rear: 10-51
PEDALIER
Integrated in Drive Unit
MANILLAR
Aluminium, 800 mm, rise: 30 mm, backsweep: 9°
POTENCIA
FOCUS C.I.S. 2.0 MTB, 35 mm, aluminium
DIRECCIÓN
ACROS ZS56/ZS56 (ICR), FOCUS C.I.S. Integrated, 1.5/1.5″ angle headset
SILLIN
fi’zi:k Taiga
TIJA DE SILLÍN
Post Moderne dropper post PM-MT171, 31.6 mm
PINZA DE FRENO
Magura MT5
MANETAS DE FRENO
Magura MT5
FRENOS
Disc
AROS
RaceFace AR30 Offset
BUJES TRASEROS
Novatec D462, 12×148 mm
BUJES DELANTROS
Novatec D041, 15×110 mm
CUBIERTAS
Maxxis Assegai, 2.5, 3C MaxxTerra Exo TR, 63-622
REAR TIRE
Maxxis Dissector 2.4, WT 3C MaxxTerra Exo TR, 61-622
MARCHAS
12
PESO EN KG. INCLUYENDO BATERÍA
19,7 kg
